SECTION IV – REPAIR 7-更换钢丝螺套、螺柱、衬套、销钉和螺母板-H.Method No. 407H：松动、磨损或损坏的 Rosan螺柱和钢丝螺套的更换-航修札记

7.Replacing Inserts, Studs, Bushings, Pins and Nutplates

更换钢丝螺套、螺柱、衬套、销钉和螺母板

H.Method No. 407H: Loose, Worn, or Damaged Rosan Stud and Insert Replacement

Method No. 407H：松动、磨损或损坏的 Rosan螺柱和钢丝螺套的更换

Loose, worn, or damaged Rosan studs and inserts are repaired using different procedures. Step (1) describes how to replace a Rosan stud, and Step (2) describes how to replace a Rosan insert. Refer to Figure 408.

松动、磨损或损坏的Rosan螺柱和嵌件需采用不同方法进行修复。步骤(1)说明如何更换Rosan螺柱，步骤(2)说明如何更换Rosan嵌件。请参见图408。

(1) Replace defective Rosan studs.

更换损坏的（有缺陷的）Rosan螺柱

CAUTION: EXERCISE CARE NOT TO DAMAGE ASSEMBLY IN WHICH STUD IS INSTALLED.

注意：安装螺柱时需小心，避免损坏组件。

(a) Cut stud off approximately flush with surface of parent material. Center punch over flat end of stud.

将螺柱切割至与母材表面大致齐平，在螺柱的平头端进行中心冲孔。

(b) Use a slightly oversize drill bit, large enough to cut inner serrations of lock ring. Remove enough of stud to remove serrations.

使用稍大尺寸的钻头，其直径需足以切除锁环的内锯齿。钻除足够的螺柱部分以消除锯齿。

在螺柱上钻一小孔，以便安装适配的“easyout”工具。

CAUTION: DO NOT ALLOW “EASYOUT” TO CATCH ON LOCK RING.

注意：切勿让“EASYOUT”卡在锁环上。

(d) Install “easyout” tool into stud and remove out of assembly.

将“easyout”工具装入螺柱后从组件中取出。

NOTE: The remainder of lock ring must come out with the stud.

注：锁环残余部分必须随螺柱一同取出。

WARNING: USE THE CORRECT PERSONAL PROTECTION. COMPRESSED AIR WILL CAUSE LOOSE PARTICLES THAT CAN GET IN YOUR EYES. COMPRESSED AIRFLOW CAN CAUSE CUTS, DO NOT POINT IT AT YOUR SKIN.

警告：务必佩戴正确的个人防护装备。压缩空气会产生松散颗粒，可能进入眼睛。气流可能造成割伤，切勿对准皮肤。

(e) Remove unwanted material from hole. Use dry, clean compressed air.

清除孔洞内多余材料。使用干燥清洁的压缩空气。

(f) Install new stud into assembly. Refer to applicable manual.

将新螺柱装入组件。参照适用手册操作。

(g) Drive or press lock ring into position.

敲击或压入锁环至指定位置。

(2) Replace defective Rosan Inserts.

更换损坏的Rosan嵌件。

WARNING: USE THE CORRECT PERSONAL PROTECTION. PROCEDURES THAT NEED GRIND/MACHINE WORK WILL CAUSE LOOSE PARTICLES THAT CAN GET IN YOUR EYES.

警告：必须使用正确的个人防护装备。涉及研磨/机械加工的工序会产生松散颗粒，可能进入眼睛。

CAUTION: EXERCISE CARE NOT TO DAMAGE ASSEMBLY IN WHICH INSERT IS INSTALLED.

注意：操作时务必小心，避免损坏安装有衬套的组件。

(a) Mill lock ring unit only a thin shell remains. Use a rotary mill of appropriate size.

用尺寸合适的旋转铣刀将锁环单元铣削至仅剩薄壳。

(b) Remove remainder of lock ring with a scribe or other suitable tool.

用划针或其他合适工具清除锁环残余部分。

将尺寸匹配的“easyout”工具插入钢丝螺套，从组件中取出。

WARNING: USE THE CORRECT PERSONAL PROTECTION. COMPRESSED AIR WILL CAUSE LOOSE PARTICLES THAT CAN GET IN YOUR EYES. COMPRESSED AIRFLOW CAN CAUSE CUTS, DO NOT POINT IT AT YOUR SKIN.

警告：请使用正确的个人防护装备。压缩空气会导致松散颗粒飞溅，可能进入眼睛。压缩气流可能造成割伤，切勿将气流对准皮肤。

(d) Remove unwanted material from hole. Use dry, clean compressed air.

用干燥清洁的压缩空气清除孔内杂质。

(e) lnstall new insert into assembly. Refer to applicable manual.

将新钢丝螺套装入组件。请参照适用手册。

(f) Drive or press lock ring into position.

将锁环敲入或压入指定位置。
